SGD$219,202
Owner: CapitaLand Ascendas REIT
District: 22
URA Permissible Land Use (Master Plan 2019): Business 2
Unit Types:
B2 Warehouse (ramp up): 87,681.39 to 88,107.86 sqft (from $2.50 psf per month)
The facility boasts enhanced features which include high power provision for cold storage usage, large contiguous floor plate with high ceiling of up to 12 metres, and more than 80 loading bays. It is ideal for third party logistics (3PL) and end users with last mile delivery operations.
5 Toh Guan Road East Typical Unit Floor Plan
Accessibility
• Within a minute drive to Pan-Island Expressway and 5- minute drive to Ayer Rajah Expressway
• 2-minute drive from Jurong East MRT station
Building Specifications
Type of Building
• 6-storey ramp up logistic warehouse with rooftop parking • BCA Green Mark Gold Plus
Floor Area
• Total NLA: Approx. 46,318 sqm
Typical Floor Plate
• 1st storey - 5th storey: Approx. 7,800 sqm
• 6th storey: Approx. 5,700 sqm
Floor Loading
• 25.0 kN/sqm
Ceiling Height
Floor to floor
• 1st storey to 6th storey: 12.0 m
Column Grid
• Approx 11.4m x 11.4m
Lifts
• Passenger lift: 3 x 750 kg (10 persons)
• Service lifts: 1 x 2 tonnes
Loading Bay Facilities
• 82 nos. hydraulic type lifts
- Dimension: 2.0 m (W) x 2.8 m (L)
- Lip extension: 0.5 m
- Frame height: 0.5 m
- Capacity: 12,500 kg
• 1st storey to 5th storey: 14 loading/unloading bays with dock levellers per floor
• 6th storey: 12 loading loading/unloading bays with dock levellers per floor
Parking Lots
• Car: 2 bays at 1st storey
• Lorry:
- 1st storey:
7.5m Lorry: 2
40 FT: 12
- 2nd storey to 5th storey:
7.5m Lorry: 6
40FT: 8
- 6th storey
7.5m Lorry: 3
40FT: 9
Container 40FT: 16
• Motorcycle: 1 bay at 1st storey
• Bicycle: 30 bays at 1st storey
Power Supply Provisions
• 1,400 amps per floor
Provisions
• ESFR Fire sprinkler system for all warehouse spaces designed to SS CP 52
• Closed circuit TV system
