Ascent

Specifications

ACCESSIBILITY
• 2 minutes’ walk to Kent Ridge MRT Station
• Walking distance to National University Hospital, National University Health System and National University ofSingapore (NUS)
• 15 minutes’ drive from Central Business District and from Clementi and Buona Vista MRT Stations

Shuttle Services
• To Singapore Science Parks 1 and 2, NUS and Kent Ridge MRT station ($0.40 per trip)

BUILDING SPECIFICATIONS
Type of Building
• 7-storey Business Park Space
• Single storey F&B, Retail and Services Space

Floor Area
• Total NLA:
- Business Park Space: Approx. 39,056 sqm
- Retail / F&B Space: Approx. 4,189 sqm

Typical Floor Plate
• Business Park Space: Approx. 70 sqm to 7,267 sqm
• Retail / F&B Space: Approx. 34 sqm to 1,214 sqm

Floor Loading
• 1st - 7th storey: 5.0 kN/sqm
• Roof:
7.5 kN/sqm (M&E)
1.5 kN/sqm (General)

Ceiling Height
• Floor to ceiling clear height
- Business Park Space: 3.0 m
- Retail / F&B Space: 4.0 m

Column Grid
• Generally: Approx. 9.0 m x 9.0 m
• Upper storey: Approx. 9.0 m x 18.0 m

Lifts
• Passenger lifts:
- Business Park Tower: 6 per tower x 1,630 kg (24 persons)
- Retail car park: 1 x 1,020 kg (15 persons)
• Service lifts:
- Business Park Tower: 1 per tower x 3,000 kg
- Dimension: 2.0 m (W) x 3.0 m (D) x 2.8 m (H)
- Lift car door size: 2.0 m (W) x 2.6 m (H)
- Retail / F&B Space: 2 x 3,000 kg
- Dimension: 2.0 m (W) x 1.9 m (D) x 2.7 m (H)
- Lift car door size: 2.0 m (W) x 2.5 m (H)

Loading Bay Facilities
• 5 loading/unloading bays with 2 dock levellers

Parking Lots
• Car: Approx. 300
• Motorcycle: Approx. 48
• Bicycle: Approx. 10
• Parking lot allocation: 1 lot per 200 sqm leased

Air-conditioning System
• Business Park Space
- Central chilled water system
- Air-con provided from Mon to Fri (8am - 6pm) except Public Holidays
• Retail/F&B Space
- Fan Coil Unit for Retail/F&B units and Air Handling Unit with chilled water connection for Food Court

Air-conditioning Charges
• After office hours: $60 per hour
• Chilled water supply is available (subject to terms and conditions)

Power Supply Allocation
• Business Park Space: Approx. 85 watts per sqm of lettable area (3-Phase)
• F&B Space: Approx. 220 watts per sqm of lettable area (3-Phase)
• Retail Space: Approx. 130 watts per sqm of lettable area (3-Phase)

Provisions
• General lighting for Business Park Space at average of 500 lux
• Floor traps for wet pantry connection
• Automatic fire alarm and sprinkler system
• 24-hour security surveillance
• Contactless proximity smart card system at turnstiles

Amenities
• Meeting rooms, auditorium and fitness centre with swimming pool at Oasis
• Food and Beverage outlets at Ascent, Cintech I, Oasis and One@KentRidge
• Retail shops and supermarket at One@KentRidge
