1. FOUNDATION
Reinforced concrete I steel piles to engineer's design
2. SUPER-STRUCTURE
Reinforced concrete structure to engineers specifications
3. WALLS
External
- Pre-cast Walling Panels I Common clay brick
Internal
- Pre-cast Walling Panels I Common clay brick
4. ROOF
Flat roof
- Reinforced concrete roof with waterproofing and insulation
5. CEILING
Living / Dining / Bedrooms
- Skim coat and I or plaster ceiling boards
Household Shelter & Yard
- Emulsion paint emulsion finish
Master Bath / Common Toilet / Kitchen
- Moisture resistant plaster ceiling boards with emulsion paint finish
6. FINISHES
Wall (For Apartments)
Living / Dining / Bedrooms / Household Shelter
- Cement and Sand plaster and / or skim coat with emulsion paint
Master Bath / Common Toilet
- Ceramic tiles laid up to false ceiling height (exposed area only)
Kitchen
- Cement and sand plaster with emulsion paint / stainless steel
Wall (For Common Areas)
1st Storey Lift Lobbies
- Granite I Ceramic tiles up to false ceiling height (exposed areas only)
Typical lift lobbies
- Ceramic tiles up to false ceiling height (exposed areas only), and/or cement and sand plaster with emulsion paint
Staircases
- Cement and sand plaster and I or skim coat with emulsion paint
Wall (For Common Areas)
External Wall
- Cement and sand plaster and I or skim coat with weather proof paint
Floor (For Apartments)
Living / Dining
- Compressed marble
Bedroom / Study
- Timber strip flooring with similar skirting
Master Bath / Common Toilet
- Ceramic Tiles
Kitchen / Household Shelter
- Ceramic Tiles
Planter box
- Smooth cement finish
A/C Ledge
- Smooth cement finish
Balcony
- Compressed marble / Ceramics tiles
Roof Terrace
- Ceramics tiles
Floor (Common Areas)
a) 1st stories lift lobbies
- Granite / Ceramic tiles
b) Typical lift lobbies
- Ceramic tiles
c) Staircases
- Smooth cement finish
d) Pool Area
- Pebble wash / Timber deck / Granite tiles
e) Walkway / Pavement
- Granite tiles / Pebble wash
7. WINDOWS
a) Powder coated aluminum framed windows with 6mm thick clear glass
8. DOORS
a) Main Entrance
- Fire-rated timber veneer door
b) Bedrooms / Bathrooms
- Semi-hollow core timber veneer door
c) Kitchen (if applicable)
- frameless glass door
d) Household Shelter
- PSB approved blast door
e) Roof Garden
- Powder coated aluminum framed doors with float / tempered clear glass
f) Ironmongery
- Quality locksets and hinges
9. RAILINGS
Steel Framed Glass panels / Mild steel in painted finish
10. SANITARY WARES AND FITTINGS
Master Bath
a) 1 sunken bath with shower mixer, shower set and soap dish
b) 1 basin and mixer tap with shelving below
c) 1 water closet
d) 1 mirror
e) 1 toilet paper holder
Common Toilet
a) 1 shower cubicle complete with shower mixer, shower set and soap dish
b) 1 basin and mixer
c) 1 water closet
d) 1 mirror
e) 1 toilet paper holder
11. ELECTRICAL INSTALLATION I TELEPHONE / TV / FM
12. LIGHTNING PROTECTION SYSTEM
a) Lightning Protection System shall be provided in accordance with Singapore Standard CP33 1996
13. PAINTING
a) External Walls
- Weatherproof emulsion paint
b) Internal Walls
- Emulsion paint
14. WATERPROOFING
a) Waterproofing is provided to floors of Bathrooms, Kitchen, Yard, W.C., R.C. flat roof, Planter Box and where required.
15. DRIVEWAY & CARPARK
a) Surface Driveway
- Granite tiles / Ceramic tiles
b) Basement Carpark Driveway and Humps
- Reinforced concrete
16. RECREATIONAL FACILITIES
a) Swimming Pool / Wading Pool
b) BBQ
c) Gym
d) Children's Play Area
e) Landscaped Garden
17. ADDITIONAL ITEMS
a) Kitchen Cabinets
-High and low kitchen cabinets with solid surface worktop complete with sink and mixer
b) Kitchen Appliances
-Cooker hob and cooker hood, built-in oven, integrated fridge, washer dryer
c) Bedroom Wardrobes
-Built-in wardrobes to all bedrooms
d) Air-conditioning
-Multi-split air-conditioning to all Bedrooms and Living / Dining
e) Fingerprint Intelligent Digital Lockset
-To Main Entrance door
f) Digital Audio Intercom System
-To apartment units (Link to Guard House)
g) Electric Water Heater
-Hot water supply to all bathrooms and kitchen except W.C.
h) Soil Treatment
-Anti-termite soil treatment by specialist approved by the relevant authorities
i) Cable vision
-Provision of cable and outlet only
j) Closed Circuit Television (CCTV) System
-Surveillance cameras to strategic locations at Common Areas
k) Rooftop Swimming Pool / Jacuzzi
- For Type B1 and Cl only
Note:
Floorings
Granite / Marble and Compressed Marble are natural materials containing veins and tonality differences. There will be colour and markings caused by their complex mineral composition and incorporated impurities. While such materials can be pre-selected before installation, this non-conformity cannot be totally avoided. Granite tiles are pre-polished before laying and care has been taken for their installation. However, granite being a much harder material than marble cannot be re polished after installation. Hence, some differences may be felt at the joints.
Timber strips are natural materials containing veins and tonality differences. Thus, it is not possible to achieve total consistency of colours and grain in their selection and installation.
Warranties
Where warranties are given by the manufacturers and / or contractors and / or suppliers of any of the equipment and or appliances installed by the Vendor at the Unit / Building, the Vendor shall assign to the Purchaser such warranties at the time when possession of the Unit / Building is delivered to the Purchaser.
Cable Television
The Purchaser is liable to pay annual fee, subscription fee and such other fees to the StarHub Cable Vision Ltd (SCV) or any other relevant party or any other relevant authorities. The Vendor is not responsible to make arrangements with any of the said parties for the service connection for their respective subscription channels.
Layout
Layout / Location of wardrobes, kitchen cabinets, fan coil units, electrical points and plaster ceiling boards are subjected to Architect's sole discretion and final design.
Air Conditioning
The air-conditioning system has to be cleaned and maintained regularly to ensure that it is in good and proper working condition. The Purchaser is advised to engage his / her own contractor to service the air-conditioning system regularly.
