Castle Green

Castle Green

Developer: Castle Green Property Pte Ltd
No. Of Units: 664 Residential Units
Tenure: 99 Years From 01/12/1993
District: 26
TOP: 1997
Unit Types:
2-bedroom + Utility: 947 sqft (216 Units)
2-bedroom + Utility PES: 1130 sqft (32 Units)
3-bedroom + Utility: 1151 to 1216 sqft (288 Units)
3-bedroom + Utility PES: 1280 to 1593 sqft (32 Units)
4-bedroom + Utility: 1410 sqft (96 Units)

Category: Tags: , , ,

About Castle Green

Castle Green is a residential complex located at 481 Yio Chu Kang Road. This development is built by the reputable developer Allgreen Properties and comprises four towers. The unique feature of each tower is that the centre stacks are seven stories tall while those at the side are 13 stories tall, creating a visual effect of a castle.

The development features 664 residential units with sizes ranging from 947 square feet to 1,593 square feet, making it a suitable home for families, couples, and individuals alike.

Castle Green is well-equipped with an array of modern facilities and amenities that cater to the needs of its residents. The development boasts a swimming pool, children’s pool, clubhouse, gymnasium, tennis courts, and playground. For those who enjoy relaxing in nature, Castle Green’s beautiful landscaping is perfect for a stroll or reading a book.

Castle Green is in a prime location that offers residents easy access to many amenities. It is located just a short distance from several shopping malls, including AMK Hub, Junction 8, and Thomson Plaza. Residents can also enjoy easy access to several eateries and restaurants that serve a variety of local and international cuisines.

For those who need to travel further afield, Castle Green is well-connected to several major roads and expressways, including the Central Expressway (CTE) and Seletar Expressway (SLE). Public transportation is also easily accessible, with several nearby bus stops and the Yio Chu Kang and Lentor MRT Station just a short distance away.

Castle Green Location Map

Castle Green Street View

Castle Green Resale/Rental Prices






Site Map & Floor Plans

Castle Green Site Map

Site plan of Castle Green condominium located along Yio Chu Kang Road, showing the layout of Blocks 481, 483, 485, and 487 arranged around a central swimming pool. The legend indicates different unit types (A1, A1a, A2, A2a; B1, B1a, B1b, B1c, B2, B2a, B3; and C) represented in varying shades. Additional facilities such as tennis courts and a clubhouse are also visible within the gated compound.

Castle Green 2 Bedroom Plus Utility Type A1 Floor Plan

Floor plan of a 2-bedroom plus utility unit (Type A1) at Castle Green, measuring 947 square feet. The layout includes a master bedroom with an attached bathroom, a second bedroom, a common bathroom, a spacious living and dining area, a kitchen with an adjacent yard, a utility room, and a store. The image also features a site map of the development and elevation charts for Blocks 481 and 483, highlighting the unit's location within the building.

Castle Green 2 Bedroom Plus Utility PES Type A1a Floor Plan

Floor plan of a 2-bedroom plus utility unit with Private Enclosed Space (Type A1a) at Castle Green, spanning 1,130 square feet. The layout includes a master bedroom with an ensuite bathroom, a second bedroom, a shared bathroom, a combined living and dining area, and a spacious kitchen connected to a yard and utility room. The unit features a private enclosed outdoor area. Elevation diagrams for Blocks 485 and 487 show the distribution of Type A1a units within the development.

Castle Green 2 Bedroom Plus Utility Type A2 Floor Plan

Floor plan of a 2-bedroom plus utility unit (Type A2) at Castle Green, sized at 947 square feet. The layout includes a master bedroom with an ensuite bathroom, a second bedroom, a common bathroom, a spacious living and dining area, a kitchen with an adjacent yard and utility room, and a separate store. The image also shows the overall site map of the development and elevation charts for Blocks 481 and 483, highlighting where Type A2 units are located.

Castle Green 2 Bedroom Plus Utility PES Type A2a Floor Plan

Floor plan of a 2-bedroom plus utility unit with Private Enclosed Space (Type A2a) at Castle Green, covering 1,302 square feet. The layout features a master bedroom with attached bathroom, a second bedroom, a common bathroom, a spacious living and dining area, a kitchen with adjacent yard and utility space, a store room, and a large private outdoor area. Elevation diagrams for Blocks 485 and 487 are also included, indicating the unit’s location within the development.

Castle Green 3 Bedroom Plus Utility Type B1 Floor Plan

Floor plan of a 3-bedroom plus utility unit (Type B1) at Castle Green, with a total area of 1,151 square feet. The layout features a master bedroom with ensuite bathroom, two additional bedrooms, a common bathroom, a spacious living and dining area, a kitchen, a yard, a WC, a utility room, and a store. The image also includes the site map of the development and elevation charts for Blocks 481 and 483, indicating the location of Type B1 units.

Castle Green 3 Bedroom Plus Utility PES Type B1a Floor Plan

Floor plan of a 3-bedroom plus utility unit with Private Enclosed Space (Type B1a) at Castle Green, covering 1,280 square feet. The unit layout includes a master bedroom with ensuite bath, two additional bedrooms, a shared bathroom, a spacious living and dining area, a kitchen with yard, a WC, a utility room, a store, and a large private enclosed outdoor space. Elevation diagrams for Blocks 485 and 487 identify the locations of Type B1a units within the development.

Castle Green 3 Bedroom Plus Utility Type B1c Floor Plan

Floor plan of a 3-bedroom plus utility unit (Type B1c) at Castle Green, with a total area of 1,151 square feet. The layout features a master bedroom with ensuite bathroom, two additional bedrooms, a common bathroom, a spacious living and dining area, a kitchen, a WC, a yard, a utility room, and a store. Elevation diagrams for Blocks 485 and 487 are included at the bottom, indicating the locations of Type B1c units within the development.

Castle Green 3 Bedroom Plus Utility PES Type B1b Floor Plan

Floor plan of a 3-bedroom plus utility unit with Private Enclosed Space (Type B1b) at Castle Green, measuring 1,345 square feet. The layout includes a master bedroom with ensuite bath, two additional bedrooms, a shared bathroom, a living and dining area, a kitchen, a WC, a yard, a utility room, a store, and a spacious private outdoor area. A site map and elevation charts for Blocks 481 and 483 are also shown, highlighting the unit's location within the development.

Castle Green 3 Bedroom Plus Utility PES Type B2a Floor Plan

Floor plan of a 3-bedroom plus utility unit with Private Enclosed Space (Type B2a) at Castle Green, covering 1,593 square feet. The layout features a master bedroom with attached bathroom, two additional bedrooms, a shared bathroom, a spacious living and dining area, a kitchen, a yard, a WC, a utility room, a store, and an expansive private outdoor space. Elevation charts for Blocks 485 and 487 are displayed at the bottom, indicating the placement of Type B2a units within the development.

Castle Green 3 Bedroom Plus Utility Type B2 Floor Plan

Floor plan of a 3-bedroom plus utility unit (Type B2) at Castle Green, with a total area of 1,216 square feet. The layout includes a master bedroom with ensuite bathroom, two additional bedrooms, a shared bathroom, a spacious living and dining area, a kitchen, a yard, a WC, a utility room, and a store. The image also features the development's site map and elevation diagrams for Blocks 481 and 483, showing the location of Type B2 units within the project.

Castle Green 3 Bedroom Plus Utility Type B3 Floor Plan

Floor plan of a 3-bedroom plus utility unit (Type B3) at Castle Green, measuring 1,173 square feet. The layout features a master bedroom with ensuite bath, two additional bedrooms, a common bathroom, a spacious living and dining area, a kitchen with an adjoining yard, a WC, a utility room, and a store. A site map and elevation diagrams for Blocks 481 and 483 are also included, showing the location of Type B3 units within the development.

Castle Green 4 Bedroom Plus Utility Type C Floor Plan

Floor plan of a 4-bedroom plus utility unit (Type C) at Castle Green, spanning 1,410 square feet. The layout includes a master bedroom with ensuite bathroom, three additional bedrooms, two common bathrooms, a spacious living and dining area, a kitchen with adjoining yard, a WC, a utility room, and a store. Elevation diagrams for Blocks 485 and 487 are shown at the bottom, identifying the placement of Type C units within the development.

Specifications

Foundation
Precast reinforced concrete piles.

Superstructure
Reinforced concrete using grade 30 concrete manufactured from Portland cement complying with BS12 and steel reinforcement bar complying with BS4449.

Walls
(1) External Wall : Clay brick with plastering
(2) Internal Wall : Clay brick with plastering

Roof
(1) Pitch Roof : Clay roof tiles with one layer of double sided aluminium foil and fibre glass insulation on tanalised timber rafters.
(2) Flat Roof : Reinforced concrete roof with waterproofing membrane, insulation and roofing panels.

Ceiling
(1) Water resistance ceiling board with emulsion paint to bathrooms.
(2) Plaster and emulsion paint to other areas.

Finishes :
(1) Walls
(a) Internal Wall
(i) Internal height (up to false ceiling) ceramic wan tiles: exposed wall surfaces of bathrooms and kitchen.
(ii) Full height (up to ceiling) ceramic wall tiles: exposed wall surfaces of WC.
(iii) Plastering with emulsion paint for all other internal walls: living, dining, bedroom, utility, stores.

(b) External Wall
Plaster and spray textured coating/emulsion paint finish

(2) FLOOR
(a) Ceramic Tiles: Living, open terrace, dining, kitchen, bathroom, utility, w.c., lift-lobbies.
(b) Parquet: Bedrooms
(c) Cement & Screed: service ducts, switch rooms, staircase, plant room, pump rooms.

(3) WINDOWS
(1)(a) Powder-coated aluminium framed casement window with fixed glass panel below - Living/Dining of type Al, A2, Bl, Bic, B2, B3 & C.
(b) Powder coated aluminium framed casement window - Bedrooms
(c) Powder coated aluminium framed top hung window - Bathrooms
(d) Powder coated aluminium framed adjustable louvre window - Kitchen except for first storey
(e) Powder coated aluminium framed adjustable louvre window with fixed grille - first storey unit kitchen
(f) Fixed louvre window to w.c.
(2) Glazing - 6mm thick bronze tinted/obscured/laminated glass

(4) DOORS (1)
(a) Fire-rated solid core timber door - Main Entrance
(b) Timber flush door - Bedrooms
(c) Powder coated aluminium framed sliding door - Living at type Ala, A2a, Bla, Blb, B2a
(d) Timber flush door with fixed glass panel - Kitchen
(e) Water-proof plywood flush door - Bath/w.c.
(f) Timber louvred door - store/utility
(2) Selected locksets

Sanitary Fittings :
(1) Master Bathroom
Long bath :1 no
Soap holder :1 no
Shower : 1 no
Paper holder : 1 no
Water closet : 1 no
Towel rail : 1 no
Mirror : 1 no
Shower screen : 1 no
Soap and sponge holder :1 no

(2) Common Bathroom
Shower : 1 no
Paper holder : 1 no
Water closet :1 no
Towel rail : 1 no
Mirror :1 no
Shower screen : 1 no
Soap holder : 1 no

(3) W.C.
Shower and tap point :1 no
Paper holder : 1 no
Wash basin : 1 no
Soap holder : 1 no
Water closet :1 no

Electrical Installation
A1a A2a B1a B1b B1c B2a A1 A2 B1 B2 B3 C
Ceiling Light Point 11 10 11 11 11 13 11 10 11 13 15 15
Wall Light Point 2 2 2 2 2 2 2 2 2 2 2 3
13A Switch Socket Outlet 9 9 11 11 11 12 9 9 11 12 11 13
13A Twin Switch Socket Outlet 3 3 3 3 3 3 3 3 3 3 3 3
Bell Point 1 1 1 1 1 1 1 1 1 1 1 1
Telephone Outlet 3 3 4 4 4 4 3 3 4 4 4 5
FM/TV Outlet 3 3 4 4 4 4 3 3 4 4 4 5
20 A DP Isolator (For Aircon) 2 2 2 2 2 2 2 2 2 2 2 3
Water Heater Point 3 3 3 3 3 3 3 3 3 3 3 4
15 A Switch Socket Outlet 4 4 4 4 4 4 4 4 4 4 4 4
Audio Intercom Set 1 1 1 1 1 1 1 1 1 1 1 1


Lightning Protection
Lightning protection system shall be provided in accordance with Singapore Standard CP.

Painting
1) Exterior: spray textured coating
2) Interior: water-based acrylic emulsion paint

Water Proofing
Waterproofing provided to basement carpark, r.c. flat roof, open deck, lift pit wall, swimming pool.

Driveway And Car Parks
1) External
(a) Driveway: interlocking paver or tiles/premix macadan
(b) Car park : Premix macadan
2) Basement
(a) Driveway: concrete floor with hardener
(b) Car park: concrete floor with hardener

Recreation Facilities
• Swimming pool
• Wading pool
• Spa pool
• Fitness corner
• Children's play area
• Barbecue Area
• Tennis Court -3 nos.
• Jogging Track
• Mini-Golf driving range -2 nos.
• Squash Court -2 nos.
• Badminton Hall
• Gymnasium
• Function Room
• Meeting Room
• Sauna-1 no. each for male and female

Other Items
1) Kitchen Cabinets: High and low-level timber kitchen cabinets with double bowl sink.
2) Wardrobes: Built-in wardrobe to all bedrooms.
3) Air-conditioning system: Air-cooled split system comprising of outdoor condensing units and indoor fan coil unit serving living, dining and all bedrooms.
4) Appliances: A cooker hob, cooker hood, an oven to kitchen. Storage water heater with hot water supply pipework to bathrooms and kitchen.

Description Of The Housing Project
1) General Description : Proposed condominium housing development comprising 664 units of apartments (13 storey, 8 storey & 7 storey) with 1 basement carpark and provision for swimming pool, squash courts, tennis courts and other ancillaries on lots 12930, MK 18 at Yio Chu Kang Road/Ang Mo Kio Ave 6

2) Details of Building Specifications : As in the above schedule

3) Type of residential units located in the building project : Apartment

4) Total No. of units : 664 units

5) Common properties includes management office, squash courts, tennis courts, badminton hall, male and female changing room, sauna, gymnasium, function room, meeting room, swimming pool, wading pool, spa pool, children play area, barbecue pit, mini-golf driving range, jogging track, staircases, bin centre, bin chambers, consumer switch rooms, guard houses, car park lots and driveways.

6) Description of car parking spaces : 685 nos of covered carpark : 102 nos of surface carpark

7) Purpose of building project and restriction to use : Residential

DEVELOPER : CASTLE GREEN PROPERTY PTE LTD
DEVELOPERS LICENCE NO. : B 0474
TENURE OF LAND : 99 YEARS LEASE (FROM 1ST DEC 1993) ON LOTS 12930 MK 18 AT Y10 CHU KANG ROAD/ANG MO RIO AVE 6
EXPECTED DATE OF VACANT POSSESSION : 30TH NOVEMBER 1997
EXPECTED DATE OF LEGAL COMPLETION : 31ST DECEMBER 1999
BUILDING PLAN APPROVAL NO. : BP 4627/9
