Mandai Foodlink

Specifications

1. Foundation
Piling system to structural Engineer's detail and/or design

2. Super Structure
Reinforced concrete and/or post-tensioned structures

3. Walls
Precast concrete panel and/or reinforced concrete and/or brickwall

4. Roof
Reinforced concrete structure with water proofing & insulation and/or metal roof with insulation

5. Ceilings
Skim coat and/or suspended false ceiling

6. Finishes
Walls
External: Cement sand plastering and/or skim coat with paint finish.
Internal: Skim coat/paint finish; homogeneous tiles to toilets walls, refuse chutes points and bin centre

Floors
Factory Units: Power float with hardener
Canteen/Toilets/Bin Centre: Anti-slip homogeneous tiles with water proofing
A/C Ledge: Cement sand screed finish with water proofing
Lift Lobby: Ceramic tiles/homogeneous tiles
Staircases/Services Rooms: Cement sand screed finish

7. Windows
Aluminium framed glass windows and/or fixed glass panels

8. Doors
Metal and/or timber doors

9. Plumbing and Sanitary Installations
Plumbing & sanitary installation are provided in accordance with statutory requirements. Scupper drain and sampling sump are provided for each factory unit in accordance with statutory requirements.

10. Electrical Installations
100amps 3 Phase electrical isolator is provided at all factory units.

11. TV/Cable Services/Telephone Points
Telecom termination box is provided at each unit. Unit owners are to make own application to Service Providers as required for telecom cabling from the risers to their own units.
MATV/SCV ready tap-off points are provided at riser. Infrastructure for broadband services is available at riser and Unit Owners are to make own application to Service Providers as required.

12. Lightning Protection
Lightning protection system is provided in accordance with prevailing code of practice.

13. Painting
Weatherproof emulsion paint on external surfaces and emulsion paint on internal surfaces where applicable.

14. Water Proofing
Water proofing is provided to all toilets

15. Turfing
In compliance with NPark's requirements

16. Additional Items
a. Floor Loading Capacity
Usage Live Load (KN/M2)
1st Storey
Production 15.0
Driveway & Ramp 15.0
2nd to 11th Storey
Production 10.0
Driveway & Ramp 10.0

b. Floor to Floor Height
1st to 11 Storey: 7.0m
Mezzanine Storey: 3.0m floor to floor height

c. Lifts
1 Goods lift 1 Service lift 1 Passenger lift

d. Fire Protection
Fire protection system provided in compliance with statutory requirements

e. Air-Con Ledge
All factory units are provided with A/C ledge only.

f. Artificial Lighting
Lighting provided to all common staircases, driveway, common toilets and external areas.

g. Mechanical Ventilation
Mechanical ventilation system is provided in designated areas in compliance with statutory requirements. Mechanical ventilation for toilets inside the factory units where natural ventilation cannot be achieved.

h. Refuse Disposal
Centralised bin centre
Refuse chute provided and accessible in every unit except unit stack #02-08 to #11-08

i. Other Provisions
Security CCTV surveillance to designated areas. Individual masonry exhaust shaft provided from unit up to the roof; tenant to supply own fans and controls. CityGas supply pipe is capped-off at the factory unit for tenant's connection and application to CityGas.
