Foundation
Spun Pile
Superstructure
Reinforced concrete structure using grade 35 concrete.
Walls
External wall : Reinforced concrete and or brickwall
Internal wall : Reinforced concrete and / or brickwall and or drywall system
Roof
Flat roof :
Reinforced concrete flat roof with appropriate thermal insulation and waterproofing system.
Metal roof :
Aluminium roof with rock wool insulation.
Ceiling
A Living / Dining / Bedrooms / Yard / Utility :
Gypsum plaster ceiling boards.
B. Kitchen & Bathrooms :
Water resistant gypsum plaster ceiling boards.
C. Household Shelter :
Cement & sand plaster to soffit of slab.
Finishes
A Internal walls :
i) Living / Dining / Bedrooms :
Cement & sand plaster.
ii) Master Bathrooms :
Marble tiles laid up to false ceiling.
iii) Bathrooms. Kitchen & WC :
Ceramic tiles laid up to false ceiling.
B. External walls :
Cement & sand plaster with textured coating.
C. Floor
i) Living / Dining :
Marble / compressed marble tiles with marble skirting.
ii) Bedrooms :
Teak timber strip with timber skirting.
iii) Master Bathroom :
Marble tiles.
iv) Kitchen /Yard / Utility / WC & Household Shelter:
Ceramic tiles.
v) Bathrooms :
Homogeneous / or ceramic tiles.
Windows
Aluminium framed casement / sliding / top hung windows with / without fixed glass panel.
Note:
1) Aluminium Frame should be powered-coated.
2) Glazing shall be approximately 6mm thick tinted glass except glazing to bathrooms which shall be 6mm thick frosted glass.
Doors
A. Entrance :
Approved fire-rated timber door.
B. Bedrooms, Bathrooms :
Quality hollow core timber door.
C. Kitchen :
Timber door with infill fixed dear glass panel.
D. Utility :
Hollow core timber door / bi-fold door.
E. Household Shelter :
Steel door as approved by relevant authority.
Ironmongery
Quality imported lockset.
Sanitary Fittings
i) Bathrooms
- 1 Shower cubicle complete with shower mixer
- 1 Solid surface vanity top with wash basin and mixer tap
- 1 Pedestal water closet
- 1 Mirror
- 1 Soap holder
- 1 Paper holder
- 1 Tower rail
- 1 Bib tap
ii) Yard
- I Bib tap
Electrical Schedule
A. Concealed electrical wiring in conduits below ceiling level. Electrical wiring above false ceiling.
B. Refer to electrical scheduled for details.
TV / Cable Vision / Telephone
Television outlet for Cable Vision Services will be provided. Refer to electrical schedule for details.
Lightning Protection
Lightning Protection system shall be provided in accordance with Singapore Standard CP33.
Painting
A. Internal walls - Emulsion paint
B. External walls -Textured coating paint finish
Waterproofing
Waterproofing to floors of kitchen, bathrooms, WC, yard, planter boxes and reinforced concrete flat roof.
Driveway and Carpark
A. Driveway - Interlocking concrete or clay paving blocks.
B. Basement carpark lot I driveway - Reinforced concrete slab with hardener.
Recreation Facilities
A. Swimming Pool
B. Barbecue Pits
C. Children's Playground
Additional Items Provided
A Water Heater Hot water supply to all bathrooms & kitchen.
B. Auto Gate Barrier
C. Pedestrian Card Access System
D. Kitchen Cabinets High & low level kitchen cabinets complete with stainless steel sink with mixer, cooker hob and hood.
E. Air-Conditioning Multi-split wall mounted air-conditioning units to living, dining, family and all bedrooms.
F. Video /Audio Intercom Video /Audio Intercom System to individual units.
Notes:
1. Marble are natural stone material containing veins with tonality differences, There will be colour and marking caused by their complex mineral composition and incorporated impurities, while such material can be pre-selected before installation, this non-conformity cannot be totally avoided.
2. Multi-split air-conditioning system has to be maintained on a regular basis by the purchasers.This includes the cleaning of filters and clearing of condensate pipes to ensure good working condition of the system.
3. The brand and model of all equipments and appliances supplied will be provided subject to availability.
4. Layout / location of kitchen cabinets and fan coil units are subject to architect's sole discretion and final design.
5. Connection, subscription and other fees for television, SCV, internet and other service providers; whether chosen by the purchaser or appointed by the vendor or the management corporation, when constituted, will be paid by the purchaser.
6. Equipment for SCV will be paid and installed by the purchaser.
7. Timber is a natural material containing grain and tonal differences. Thus it is not possible to achieve total consistency of colour and grain in its selection and installation.
