1.0 Foundation
Reinforced-concrete piles far main building structures
2.0 Superstructure
Reinforced-concrete building structure
3.0 Walls
External : Reinforced- concrete / brick wall / curtain wall
Internal : Reinforced-concrete / brick wall / drywall
4.0 Roof
Reinforced-concrete roof with appropriate insulation and waterproofing system
5.0 Ceiling
5.1 Apartment Units
a) Living / Dining, Bedroom. Study & Store :
Skim coat / cement & sand & plaster/plasterboard box-ups with emulsion paint finish
b) Hall / Stairway, Bathrooms, Powder Room, Kitchens, WC. Yard & Planters :
Skim coat / cement & sand plaster / plasterboard ceiling with emulsion paint finish
c) Household Shelter & A/C Ledges :
Skim coat with emulsion paint finish
5.2 Common Areas
a) First Storey & Typical Lift Lobbies
Plasterboard ceiling with emulsion paint finish
b) All Other Areas : Skim coat / cement & sand plaster /plasterboard ceiling with emulsion paint finish
6.0 Finishes
6.1 Walls
6.1.1 Apartment Units
a) Living / Dining, Kitchen, Hallway / Stairwey. Bedrooms, Story. Store & Yard, Household Shelter :
Cement a sand plaster/skim coat with emulsion paint finish
b) Master Bathroom
Tiles
c) Common Bathrooms & Powder Room :
Tiles
d) Kitchen &W C :
Tiles
e) Planters :
Planter with paint finish
f) Roof Terrace (PH only) :
Plaster with paint finish
g) Balcony :
Plaster with paint finish
6.1.2 Common Areas
a) First Storey :
Stone tiles / glass panels / stainless steel panels
b) Typical Storey Common Lift Lobbies & Escape Staircases ; Cement & sand plaster / skim coat with emulsion paint (lift lobbies only)
c) All External Walls :
Cement & sand plaster / skim coat wi(h textured / non-textured paint finish or framed fixed glass panels
Note:
i) No tiles / stone work behind / below cabinets, mirrors, backsplash panels, long baths and above false ceiling
ii) All wall finishes shall be terminated at false ceiling level
iii) Wall tiles up to false ceiling height and on exposed surfaces only
6.2 Floors
6.2.1 Apartment Units
a) Living / Dining, Kitchen. Hallway & Powder Room :
Tiles
b) Bedrooms, Study & Staircases :
Tiles
c) Master Bathroom :
Tiles
d) Comnmon Bathrooms, Kitchon, WC, Houseehold Shelter :
Tiles
e) Roof Terrace (PH only) :
Timber deck / Cement & sand screed
f) Planter & A/C Ledges :
Cement & sand screed
g) Balcony : Tiles
6.2,2 Common Areas
a) First Storey:
Granite / Marble Tiles
b) Typical Storey Common Lift Lobbies :
Tiles
c) Escape Staircases Cement & sand screed
7.0 Windows
Aluminium-framed windows with tinted, clear it glass where. appropriate
8.0 Doors
Apartment Units
a) Main Entrance :
Approved fire-rated timber door
b) Bedrooms & Bathrooms, Powder Room & Kitchen (PH only) :
Timber door
C) Living / Dining / Bedroom to Balcony :
Powder coated aluminium-framed glass door
d) Household Shelter
Approved household shelter metal door
e) WC :
PVC bi-fold door
f) Roof Terrace (PH only):
Powder-coated aluminium-framed tinted glass door
Note:
Selected good quality lockets and ironmongery for all doors.
9.0 Sanitary Fittings
Apartment Units
a) Master Bathroom :
1 solid surface vanity top complete with basin, mixer lop and under counter solid surface ledge
1 shower cubicle complete with mixer, hand-held shower and rain shower rose
1 wall hung water closet.
2 towel hooks
1 toilet paper holder
1 mirror
For Duplex D1, D2 and Penthouse only 1 long bath complete with bath mixer
b) Common Bathroom:
1 solid surface vanity top complete with basin, mixer tap and counter solid surface ledge
1 shower cubicle complete with mixer, hand-held shower and rain shower rose
1 well-hung water closet
2 towel hooks
1 toilet paper holder
1 mirror
C) WC
1 pedestal waler closet
1 wash basin
1 hand-held shower head
1 toilet paper holder
1 towel rail
d) Balcony (PH only) :
1 bib tap
e) Roof Terrace (PH Only) :
1 bib tap
Note: The brand, type and colour of ward, fittings and accessories me subject to Architect's selection and availability
10.0 Electrical installation
a) Refer to Electrical Schedule for details
b) All electrical wirings in conduits are concealad except tor electricial wiring in conduits exposed above the false ceiling
11.0 TV / FM / Telephone
Refer to Electrical Schedule for details
12.0 Lightning Protection
Lightning Protetion System shall be provided in accordance with Singapore Standard CP 33: 1996
13.0 Painting
a) External :
Textured / non textured external paint finish
b) Internal :
Emulson paint finish
14.0 Waterproofing
Waterproofing shall be provided to floors of Bathrooms, Kitchens, WC, Roof Terrace, RC flat roofs, Planters, Swimming Pool and as required
15.0 Driveway and Car Park
a) Entrance Driveway - Pavers
b) Car Park and Ramp Concrete floor with floor hardener
16.0 Recreation Facilities
a) Swimming Pool - 20m lap pod
b) Tennis Court
c) Basketball Half-Court
d) Sky Garden (34th floor)
e) Multi-Function Room
f) Gymnasium
g) Jacuzzi
h) Other Facilities - Male and Female Showers / Changing Rooms
17.0 Other Items
a) Kitchen Cabinets ;
High and low level kitchen cabinets complete with solid surface countertop and sink with mixer
b) Bedroom Wardrobes
Wardrobes provided in all common Bedrooms and Master Bedrooms (No wardrobe for bedroom 2 of Type C)
c) Air-Conditioning
Wall-mounted split-unit system
d) Electrical Water Heater :
Hot water supply to all Bathrooms and kitchen
e) Security
i) Proximity card access entrance lobbies and lift access to unit,
ii) Audio intercom system to every unit
ill) CCTV
iv) Auto car barrier with transponder access
f) SCV :
SCV Cable Ready will be provided (not Inclusive of cable TV subscription)
g) Kitchen Appliances
i) Hood
ii) Hob
iii) Fridge
iv) Washing Machine cum Dryer
v) Microwave. Oven
